Specifications

Capacity: 4500lbs(2000kgs)
Drive: Electric
Height, fork lowered: 75mm
Height of tiller in drive position, min./max.:1250-800mm
Overall length: 1620mm
Fork Length: 1220mm
Overall width: 685mm
Distance between fork-arms: 685mm
Ground clearance, centre of wheelbase: 19.5mm
Travel speed, laden/unladen: 4.0/5.0 km/h
Lifting speed, laden/unladen: 18/23 mm/s
Lowering speed, laden/unladen: 56/46 mm/s
Max. gradeability, laden/unladen: 6%/20%
Drive motor: DC 1.0 Brushless
Lift motor: DC 0.8
Battery voltage/nominal capacity: 48V/10Ah
Traveling brake: Regenerate
Brake: Electromagnetic
Sound level at the driver’s ear according to EN 12053: ＜70dB

Warranty

Warranty Terms and Conditions (EN)
Conditions de Garantie (FR)

Packing Details

Packing size: Inches
Packing weight: lbs
