Model: SS306022DP
Features

Frame Work: Straight Wall Peak Double Truss with hot dipped galvanized steel.
Fabric Cover: Fire retardant, Water-resistant, UV protection.

Specifications

Shelter Width: 30FT
Shelter Length: 60FT
Shelter Height: 22FT
Shape: Peak / Double Truss
Cover: 22oz(610GSM) PVC
2 Front & Back winch / man doors on both ends
​Winch Door opening dimension: W 4m x H 4.8m
Winch Door clearance dimension: W 4m x H 4.3m
Man Door dimension: W 1m x H 1.9m
​Eave height: 3.77m
​Number of trusses: 7
​Approximate truss spacing: 10FT (3.05m)
​Number of large anchor plates: 14
Ventilation windows on both ends​

Warranty

Warranty Terms and Conditions (EN)
Conditions de Garantie (FR)

Packing Size

Box 1: 110' ×43' ×29'
Box 2: 124' ×43' ×49'

Packing Weight

Box 1: 1933 lbs
Box 2: 2838 lbs

Recommended Foundations:​

Concrete spread footings/padding
Poured in place concrete walls
​Precast concrete walls
Lock blocks
Sea Containers
